To remove the belt, press the red button on the lock, the belt is automatically wound on the roller (Fig. 1.210). Three-point safety belt middle rear seat space Belt is pulled from the pulling device only if the back of the rear seat is fixed in an upright position in their holders. Check belt All parts of seat belts should be from time to time to check for damage and serviceability. Damaged parts, stretched belts in the accident and worked stoppers locks must be replaced. NOTICE Nothing has changed in the seat belts, their anchorages, the automatic winding mechanism and castles belts. Avoid damage to safety-belt with sharp objects or clamping straps.
System of airbags «Opel Full Size» Fig. 1.211. The front airbag system «Opel Full Size»
System of airbags «Opel Full Size» consists of several separate systems (Fig. 1.211). System front airbags System front airbags triggered by severe frontal collisions and form a safety bumper for driver and front passenger. Progress seated forward dramatically slowed down and, thus, significantly decreasing the risk of injury to the upper body and head. System of side airbags Fig. 1.212. Side airbag system «Opel Full Size»
Side airbag system fires in side collisions and form a safety bumper for the driver or front passenger in the zone corresponding to the front door. Thus a side collision is significantly reduced risk of injury to the upper and pelvic parts of the body (Fig. 1.212).
93
