Replacing brake pipes

Attach the wiring harness in time sensor mounted on the wheel of a car (Figure 6.22). Install the front wheel and tighten the moment of 110 Nm Remove air from the brake system and check the tightness. Adjust the level of brake fluid so that it was at the tag «MAX».

Withdrawal

Fill the tank hydraulic brake system to the mark «MAX» and close with a special tool MKM-558-10.

NOTE Tubes braking system is mainly supplied without connecting bolts and razvaltsovok. Use the connecting bolts of the diameter of the tubes, if necessary making the braking system. Install the appropriate connecting bolt on the brake pipe and tube razvaltsuyte end of the braking system. Pay attention to the type of initial flaring.

Fold the new brake pipes, using pipe braking system, which will be replaced, as a model.

NOTE Use tube expanders to avoid changes in cross section.

Fig. 6.23. Expanding brake pipes
