Replace connecting rod bearings
Lay the wire along the axis between the root neck of the crankshaft connecting rod bearings and connecting rod bearing liner (Fig. 2.233). Replace the cover connecting rod bearings
NOTE To wire did not break when removing the lid connecting rod bearings, remove the grease from the crankshaft crank shaft and lightly grease the liner connecting rod bearings - do not turn the crankshaft.
Tighten the 2 bolts moment 13 Nm Dauvergne at +60 ° and +15 °. Remove the connecting rod bearings, unscrew the 2 screws.
NOTICE Do not confuse the decimal and metric information scale of measurement.
Measure the width of the flattened section of plastic wire using a measuring scale. Allowable gap in the connecting rod bearings: from 0,013 mm to 0,061 mm. Install the liner connecting rod bearings and connecting rod bearing cap. Clean the crankshaft crank shaft bearings and connecting rod bearing liner. Lightly grease the bushings connecting rod bearing. Tighten the 2 bolts moment 13 Nm and Dauvergne at +60 ° and +15 °.
NOTICE Always use screws M6, 5. Use new bolts.
Remove the oil pan.
Fig. 2.234. The order covers the
