Wipers and washers
Care wipers Fig. 1.105. Window rain sensor
In order to ensure trouble-free operation of rain sensor, window sensor must be clean from dust, dirt and ice, so periodically switch the device washing windows or remove ice from the window of the sensor. Vehicles with rain sensor has a window above the sensor on the windshield (see Figure 1.105).
Job wipers Fig. 1.106. Mode include wipers
To activate the wipers move the lever up slightly (Fig. 1.106). The lever always returns to its original position. to switch the lever to the next higher or lower stage, slightly move it up or down. To enable a single lever, slide down from the position
.
Adjustable range of wiper To adjust the cleanup interval in the range from 2 to 15 with a turn on the ignition, move the lever from the position down, wait for a while and move the lever in the position of the periodic inclusion. The installed length of the interval treatment remain stored in memory until the next change or until the ignition is turned off. After turning on the ignition and set the lever in position is set at 4 seconds.
interval inclusion
Fig. 1.107. Adjustable range of wiper
53
