Set the parking brake lever system in the position "0" (off) (Figure 6.14) Click on the brake pedal completely for at least 5 times. NOTE To adjust the status of the parking brake in the brake caliper or brake drum - make sure that every time when you turn on the parking brake, the brake pedal is returned to its original position (fully unloaded). In cars with drum brake adjuster lever mechanisms of the work can not hear. Lift the lever of the parking brake system 5 times until it stops and then pull down. Lift the lever of the parking brake for 2 clicks. Turn the adjusting nut on the parking brake lever system before any appreciable resistance to rotation of the rear wheels. NOTE Inhibitory force must be equal on both wheels. Lift the lever of the parking brake system on the 3 steps. NOTE The wheels should be blocked by 3 clicks. Attach the corrugated cuttings of the parking brake lever on the center console. Attach the lid of the diagnostic compounds.
Replacing the brake pedal Withdrawal Remove the casing pipe supporting the steering column from the top by unscrewing 2 screws fastening. Remove the casing pipe supporting the steering column from the bottom, unscrewing 3 bolts. Fig. 6.15. Removing the module light switch: 1 - Grip 2 - central location, 3 - light switch module
