Make sure that the bag sits in the grooves of the steering rod and steering mechanism.
Fig. 5.32. Installing the cover on the steering traction: 1, 2 - slots, 3 adaptation, 4 - fixing bracket
Attach the cover to the steering mechanism with a new restraint with a collar device KM-J-22610 (Fig. 5.32). Fasten the cover of the new retention bracket to the steering traction. NOTE Make sure that the bag sits in the grooves of the steering rod. Insert the tip of the steering rod. Install the bottom cover of the engine compartment. Fasten the front wheel bolts with torque 110 Nm
Replacement of pipelines hydraulic steering system with amplifier (ZF) Withdrawal Fig. 5.33. Removing the front suspension subframe: 1 - bracket damping engine block, 2 - holder, 3 - supply pipeline, 4 - reusable tube
Remove the front suspension subframe.
The vehicles left-hand steering clear bracket damping engine block rear damping block engine.
431
