Disconnect the steering traction with a special tool KM-6004-2 from the steering rack and hold an open wrench for Lyskov on rack (see Figure 5.27). Setting Attach the steering pull to the steering mechanism and tighten the moment 90 Nm Clean the threads on the rail and cover with a fixing composition. Attach the steering pull to the rail with a special tool KM-6004-2, and hold an open wrench for Lyskov on rack (arrow in Figure 5.27). Replace cover or covers. Install the appropriate tip steering traction. Check the position of the rectilinear movement, adjust if necessary. Check the convergence of the wheels, adjust if necessary.
Replacing the steering mechanism (TRW) NOTE To remove the steering mechanism must be removed the front suspension subframe. Withdrawal Remove the front suspension subframe. On vehicles with left-hand steering clear bracket damping engine block rear damping block engine. Remove the holder. Fig. 5.28. Removing the pipe from the steering meanizma: 1 - bracket damping engine block, 2 - holder, 3 - supply pipeline, 4 - return pipeline
Remove the supply pipeline and the return pipeline from the steering mechanism (Fig. 5.28). NOTE To use the resulting oil tray. Wiring harness and unleash the power steering of the front suspension subframe. NOTE Pay attention to the laying bundle. Remove the electrohydraulic module with the front suspension subframe. Fig. 5.29. Mounting electrohydraulic module: 1, 2 - Nuts
Loosen the 3 nuts from the steering and front suspension subframe (Figure 5.29).
