Clean the threads and install a new bolt fixing composition. Connect the wiring harness connector audio Install air bag module security. Attach the intermediate shaft to the steering shaft and tighten the moment 24 Nm Insert the intermediate shaft on the steering shaft. Attach the clamping bolt. NOTE Before installing the clamping bolt, make sure that the groove of the steering shaft (arrow in Figure 5.17) combined with a hole in the intermediate shaft. Clean the threads and install the bolt with a fixing composition. Check the loading position, the clamping bolt. Install intermediate shaft on the steering mechanism and attach the clamping bolt. NOTE Make sure that the wheels are in the position of the rectilinear motion Install the lower trim. Check the position of the rectilinear movement, adjust if necessary. Connect a massive wire to the battery.
Replacing the steering mechanism (ZF) NOTE To remove the steering mechanism must be removed the front suspension subframe. Withdrawal Remove the front suspension subframe. The vehicles left-hand steering clear bracket damping engine block rear damping block engine. Fig. 5.23. Removing the front suspension subframe: 1 - bracket damping engine block, 2 - holder, 3 - supply pipeline, 4 - reusable tube
Remove the holder and disconnect the supply pipeline and return pipe from the steering mechanism (Fig. 5.23). NOTE To collect oil flowing, use the tray. Remove the electrohydraulic module with the front suspension subframe. Fig. 5.24. Removing the electrohydraulic module: 1, 2 connectors wiring harnesses, 3, 4 nuts
Disconnect the 2 connectors wiring harness and remove them from the electrohydraulic module (Fig. 5.24). Loosen the 3 screws from the steering mechanism and the front suspension subframe.
424
