5.3. Steering Gear Replacing the steering column module (CIM) NOTE When replacing the control unit, before removing the control unit restart with the device CLOSE 2. Withdrawal Disconnect the battery. Remove the steering. Remove the lining of the lower steering column, unscrewing 5-bolt attachment (arrows in Figure 5.14). Fig. 5.14. Removing the panel ignition lock: 1 - panel lock
Remove the ignition switch (Figure 5.14). Remove the column module (CIM), 3 unscrewing bolts. Fig. 5.15. Removing the module: 1 - mounting screws, 2 - the wiring harness connector
Disconnect the wiring harness holder (arrow) and disconnect the wiring harness connector (Fig. 5.15).
