Fig. 4.44. Stabilizer front suspension complete with subframe: 1 - turning the lever, 2 retaining brackets, 3 - stabilizer
Remove the stabilizer (Fig. 4.44). Setting Attach the stabilizer to the front suspension subframe. Install stabilizer on the front suspension subframe. Install rubber support stabilizer. Fig. 4.45. Reliance stabilizer: 1 bracket
NOTE Check the loading position, the rubber bearing - a groove (arrow in Figure 4.45) should be turned forward (in the direction of motion). Install retaining bracket. Attach the retention bracket to the front suspension subframe and tighten the moment 20 Nm Attach the swivel arm to the stabilizer on both sides and tighten the moment 55 Nm Use 2 new nuts. During installation, hold for Lyskov open wrench. Install the front suspension subframe.
Replacing the rotary lever Withdrawal Remove the front wheel. Remove the rotary levers. Disconnect the swivel arm from the supporting tube spring rack. Hold for Lyskov bolt steering knuckle open wrench.
401
