Setting Set a rack in a spring wheel arch. Replace the spring-rack in the wheel arch. Fig. 4.36. Installing a new ring: 1 snap ring, 2 - adaptation
Attach the new circlip using appliances KM 6384 (Fig. 4.36). Set a rack in a spring swivel fist. Install 2 bolts. NOTE Install the bolts in the front. Do not tighten up camber of the wheels. Use 2 new bolt. Use 2 new nuts. Attach a swivel arm for supporting the pipe rack and tighten the spring element 65 Nm Use new nut. Hold for Lyskov open wrench. Attach the brake hose to the bracket supporting the tube spring rack. NOTE Correctly lay the hose. Install the brake hose bracket. Attach the brake hose using a clamp. Install the sensor spring rack CDC to mount the sensor on a spring rack. Tighten the attachment bolt. Install the wiring harness on a spring rack. Attach the wiring harness in the clamp spring rack. Connect 4 x wiring harness to the wiring harness. Turn the secondary locking mechanism. Slide the locking mechanism up. Install the front wheel and tighten the bolts fastening point 110 Nm Check and adjust the collapse of the wheels. Check and adjust the collapse of the wheels. 2 Tighten the hinge that supports the spring the pipe rack to the steering knuckle, in 3 hours. I. Tighten the 2 bolts moment 50 Nm II. Tighten the 2 new joint torque 85 Nm III. Dauvergne 2 new joint by 75 ° and +15 °.
Replacing the front damping arm bushings NOTE In the general case, both damping bushings must be replaced. , Withdrawal Remove the lever.
396
