Fig. 3.102. Measurement oblique gap block bearing: 1 - magnetic holder, 2 - a special tool, 3 - Bracket 4 - a special tool
Attach special tool KM-468-B of the wheel hub (see Figure 3.102). Attach special tool MKM-571-B, to the brake calipers or backplate brake mechanism with a magnetic holder, or bracket. Replace the sensor if a special tool MKM-571-B on the outer edge of the brake disc or wheel bearing. Check the clearance of raising a little bit special tool KM-468-B. The maximum permissible slope of the gap: 0,1 mm. NOTE If this value is exceeded, replace the wheel bearing. Setting Remove the special tool MKM-571-B with the bracket or magnetic holder. Remove the special tool KM-468-B. For cars with drum brake mechanisms: Set the brake drum Install the rear wheel, tighten the bolts fastening point 110 Nm
Removing and installing shaft wheel Withdrawal Remove the corresponding front wheel. Disconnect the wheel shaft of the wheel hub. Unscrew the nut on the shaft of the wheel.
369
