Slowly turn the wheel bearing. Measure the radial run. Allowable lateral beating is: 0,04 mm. NOTE If the value is not specified, replace the wheel bearing. Install special tool MKM-571-B (3) The clock display type, the bracket (1) and a magnetic holder (2) on the brake shield. Fig. 3.101. Measurement of lateral runout: 1 - Bracket 2 - magnetic holder, 3 - a special tool, 4 - sensor type indicator time
Install sensor type indicator hour front wheel bearing (as shown in Figure 3.101). Set the indicator to "0". Slowly turn the wheel bearing. Measure the lateral separation. Allowable lateral beating: not more than 0,05 mm. NOTE If the value is not specified, replace the wheel bearing. Setting Remove the special tool MKM-571-B with the bracket clock-type indicator and a magnetic holder. Install the brake disc or brake drum. Install the rear wheel and tighten the bolts fastening point 110 Nm
Measurement oblique gap block bearing NOTE If you have a wheel is significant gap, measure it, as indicated below. Withdrawal Remove the appropriate rear wheel. For cars with drum brake mechanisms: remove the brake drum.
