Tighten the 5-bolt M8 moment 20 Nm Install the front axle housing. Tighten the switch reversing lamps moment 20 Nm NOTE Use new O-ring. Replace the cover gearbox. Check the fluid level in the gearbox.
Removal and assembly of the differential (gearbox F13) NOTE Transmission is installed. Withdrawal Disconnect the shafts of the wheels of the gearbox. NOTE Shafts wheels remain in the wheel hubs. Remove the back cover by unscrewing the mounting bolts 9. Remove the back cover. Fig. 3.75. Removal of the differential: 1 - shafts of the wheels 2, 3 - back cover, 4 - differential
Remove the differential (Figure 3.75). Remove the 2 sealing rings of the shaft of the wheel cage and gearbox.
