Remove the back cover (Figure 3.53). Remove the cover gasket. NOTE If necessary, loosen the fastening lid light strikes a rubber hammer. NOTE Drain the gear oil. Disconnect the special device KM 6155. Remove the differential. Remove the working cylinder clutch. Remove the discharge pipe and discharge pipe mounting sleeve. Remove the main bearing and the shaft of the transmission housing. Remove the 2 sealing rings of the shaft wheel. Remove the transmission housing through a special device KM 6115. Setting Attach the new transmission housing to the special adaptation of the CM 6115. Install the main bearings and shaft. Install differential. Install discharge pipe and discharge pipe mounting sleeve. Install working cylinder clutch. Attach a special device KM-6155 to the gearbox. Replace the back cover. NOTE Pay attention to the magnet. NOTE Note the similarity of the bolts. Attach the rear cover. Replace it with a new gasket on the transmission housing. Tighten the 4 bolts M7 moment 15 Nm Tighten the 5-bolt M8 moment 20 Nm Replace the cover gearbox. Set switch reversing lamps. Tighten the switch reversing lamps moment 20 Nm NOTE Use new O-ring. Install 2-wheel shaft sealing ring. Install the left engine damping block Tighten the 3 bolts fastening point 55 Nm
Removing and installing the rear cover gearbox (F 13) NOTE Work is being carried on the established transmission. Withdrawal Fig. 3.54. Removing the gearbox: 1 - cover 2 - switch reversing lamps
Remove the gearbox and switch reversing lamps (Figure 3.54). Disconnect the wiring harness connector, switch reversing lamps. Unscrew the switch reversing lamps Remove the casing front axle.
350
