Attach the front and rear of the gearbox to the engine and tighten the 2 screws mounting torque 60 N m. Set pan gearbox and tighten the 3 bolts fastening point 40 Nm Attach the front damping motor unit to the gearbox and tighten the 2 screws fastening the moment 80 Nm Set shafts of the wheels. Lift the engine and transmission with the help of a special device MKM-883-1. NOTE When mounting the body of the front axle, make sure that the supporting bearing KM-6001-A properly located in the front guide pin damping engine block and rear brackets damping engine block. If necessary, adjust the loading position of the engine and gearbox, using a special device MKM-883-1. Install the front axle housing. NOTE Do not install the central silencer, front exhaust pipe, battery and battery support. Replace the air filter housing and air intake hose. Install left damping engine block. Attach to the left relying damping engine block and tighten the 3 mounting bolts are 55 Nm Attach the gearbox to the top and tighten the 4 mounting bolt torque 60 Nm Connect the discharge pipe from the socket. NOTE Cyanoacrylate clamp to latch. Connect the wiring harness connector switch reversing lamps. Remove special device KM-6001-A from the body of the front axle. Install central silencer and a front exhaust pipe. Check the fluid level in the gearbox. Attach the bottom cover of the engine compartment. NOTE If necessary, adjust the draft switching gear. Install support battery. Replace the battery pack. Program volatile memory. Remove air from the hydraulic clutch.
Transmission, removing and installing on the engine (dismantled) Withdrawal Fig. 3.40. Removing the coolant hose from the thermostat housing: 1 - coolant hose, 2 - housing thermostat
344
