Fig. 2.318. The design of the exhaust system (Z 20 LEL): 1 endpoint muffler with exhaust pipe, 2 - central exhaust pipe with a central silencer, 3 - Front exhaust pipe with a flexible tube
The chart below shows the position and location of individual components of the exhaust system (Fig. 2.318).
Replacing a refrigerator exhaust gas recirculation (2.0 liter engine) Withdrawal Open the hood. Disconnect the battery. Disconnect the grounding connector on the grounding clamp. Raise the car completely. Fig. 2.319. Lower engine compartment lid: 1 - cover
Remove the bottom cover of the engine compartment by unscrewing the mounting bolts 10 and removing the 4 rivets (Fig. 2.319). Place the bottom of the container for drainage. Drain the coolant. To do this, loosen the drain bolt on the radiator and collect coolant. Tighten the drain bolt Lower the car completely. Remove the engine. Fig. 2.320. Removing hose air pressurization: 1 - hose
Remove the hose, air pressurization, removing 2 clamp (Fig. 2.320). Remove the battery.
