To do this, disconnect the wiring harness connector and 2 air intake hose (Fig. 2.309). Remove the 2 clamps. Setting Install sensor mass air flow. Connect the intake hose. Tighten the clamp 2 point 3.5 Nm Connect the wiring harness connector. Close the hood.
Removing and installing the thermostat housing (engine 2.0 l) Withdrawal Open the hood. Disconnect the battery. Disconnect the grounding connector on the grounding clamp. Raise the car completely. Place the bottom of the container for drainage. Drain the coolant. Fig. 2.311. Drainage bolt heatsink: 1 - bolt
Loosen the drain bolt on the radiator (Fig. 2.311). Collect the coolant. Tighten the drain bolt. Lower the car completely. Remove the battery. Fig. 2.312. Removing the battery: 1 - Bracket 2 - attachment bolt, 3 positive terminal
