Fig. 2.290. The design of the fuel tank (removed): 1 - module cover, 2 - Tube fuel filler, 3 - tank removal / air ventilation - Tube fuel filler
Tube fuel filler As for Astra-G, Astra-H to remove the tank air / ventilation tube is fixed on the fuel filler.
Replacing the tube fuel filler (petrol engines) Withdrawal Open the hood. Disconnect the battery. Remove the clamp from the output of the mass of the mass. Disconnect the pipe fuel filler. To do this, open the lid hatches fuel tank filler cap (3) Fig. 2.291. Removing the tube fuel filler: 1 - plastic lid, 2 - rubber membrane, 3 - cover hatches fuel tank filler cap, 4 - bolt
Remove the fuel filler (Fig. 2.291). Remove the rubber sheath. Loosen the screw. Attach the plug fuel filler. Remove the right rear wheel. Raise the car in half. Remove the right rear wheel.
288
