Replacing the fuel level sensor Withdrawal Open the hood. Disconnect the battery. Remove the clamp from the output of the mass of the mass. Place the bottom of the container for drainage. Reset the fuel pressure using a special device KM-J-34730-91 through the test channel. NOTE Collect leaking fuel into a suitable container - observe safety regulations and national legislation. Open both rear doors Remove the bench. Fig. 2.282. Staples issuance rear seat: 1 - Staples
2 Pull the clips release (Fig. 2.282). Remove the bracket in the direction of the arrows in 2 places. Remove the bench seat of the car. Remove the cover. Bend the noise isolation and open the lid. Disconnect the wiring harness connector. Fig. 2.283. Fuel lines: 1 - fuel, 2 Connector
Mark and remove the fuel lines using a special tool KM-796-A (Fig. 2.283). Close the fuel plugs special tool KM 807 and KM 6015. NOTE Make sure that the special tool KM-797 properly and safely installed.
284
