Fig. 2.277. Using a special tool: 1 a special tool
Special tools required for removal of the fuel pump module. Figure 2.276 shows a special device KM 6391. Four guides are installed vertically into the existing fuel pump module guides for the separation module from the bracket and the lifting assembly (Fig. 2.277). For better visibility of the module is shown removed from the car.
Replacement module dosage NOTICE When working with fuel system, pay attention to cleanliness because, even the smallest particles of dirt can cause problems in the engine or fuel system. Withdrawal Open the hood. Disconnect the battery. Disconnect the connection with the mass of the output mass. NOTICE Module and the area around the dosage should be cleaned of grease. NOTICE After removing the module and the area around the dosage should be cleaned again.
280
