Replacing the radiator (2.0 liter engines) Withdrawal Open the hood. Disconnect the battery. Disconnect the connection with the mass of the output mass. Remove the grille, disconnect the 4 rivets. Disconnect from the front facing the top. Disconnect 5 times. Attach the radiator to the upper bracket. Raise the car in half. 5 Remove the rivets. Disconnect 4 times and remove the front bumper. Raise the car in half. Place the bottom of the container for drainage. Drain the coolant. Fig. 2.254. Wiring harness connector from the fan case fan: 1 connector
Disconnect the wiring harness from the fan case fan (Fig. 2.254). Undock the cable clip. Remove the right bracket of the radiator, otvernuy 2 bolts fastening. Fig. 2.255. Radiator brackets: 1 right 2 - left
Remove the left arm of the radiator, otvernuy 2 bolts fastening (Fig. 2.255). Lower the car completely. Fig. 2.256. Removing the boost pressure sensor: 1 - boost pressure sensor, 2, 3 - clamps
269
