Removing and installing cylinder head (engine 1,4-1,6 l) Withdrawal Open the hood NOTE Before the verification procedure warming up the engine to operating temperature (oil temperature - 80 ° C).
Fig. 2.212. Components, shooting in the dismantling of the air filter: 1 screw fixing the lower rubber support, 2 - wiring harness mass air flow sensor, and 3 - line of ventilation of the fuel tank, 4 - hose, ventilation motor, 5 - air intake hose, 6 - inlet pipe
Remove the air filter housing (Fig. 2.212). Disconnect the wiring harness sensor mass air flow. Disconnect the fuel tank ventilation line. Disconnect the ventilation hose from the engine air intake hose. Removing the clamp, disconnect the hose from the air intake throttle pipe. Removing the clamp, remove the air filter housing. Loosen the screw fixing the lower rubber support and unplug it. Disconnect the inlet pipe. Fig. 2.213. Removal of cooling nozzles to throttle: 1, 3 - schlangi coolant 2 - connector wiring harness throttle tube
Disconnect the wiring harness connectors throttle tube (Fig. 2.213). Disconnect the coolant hoses from the throttle tube. Place the bottom of the container for drainage. Remove the 2 clamps. Disconnect the coolant hose.
248
