NOTICE Do not apply sealer roller kremnievorganicheskogo (gray) in the slots or on the inner edge. Apply silicone sealant roller (gray) on the outer edge of the groove on the basis of the cylinder thickness about 2 mm. Attach the base of the cylinder block to (tighten by hand) 22 bolts. Use new bolts. 10 Tighten the screws on the inside (M8) moment of 25 Nm and Dauvergne at +60 °. 12 Tighten the bolts (M6) outside the point of 10 Nm and Dauvergne at +60 °.
Removing and installing cylinder head (engine 2.0 l) Withdrawal Fig. 2.209. Bolts fastening intake manifold: 1 - screw fixing
Separate the intake manifold from the cylinder head. To do this, loosen the 6 mounting bolts (Fig. 2.209). Remove the seal. Clean the sealing surfaces. Separate chain tensioner from the cylinder head. Unscrew the 2 screws fastening. Disconnect the oil pressure sensor on the cylinder head. Disconnect the exhaust gas recirculation valve from the cylinder head. Loosen the 4 bolts fastening. Remove the spark plug with a special tool KM-194-E. Check the label before the dismantling of the camshaft bearing caps. Camshaft drive exhaust valves, the identification of: 1-3-5-7-9. Camshaft drive intake valves, identification: 2-4-6-8-10. Remove the camshaft drive exhaust valves. NOTE When otvorachivanii camshaft bearing caps, provide a smooth transition from the camshaft bearing. Loosen the camshaft bearing caps gradually on 1/2-1 turnover. Loosen the mounting bolts 10. Remove the camshaft bearings. Put in the correct order. Remove the camshaft drive exhaust valves Loosen the camshaft bearing caps gradually on 1/2-1 turnover. Loosen the mounting bolts 10. Remove the camshaft bearings, put in the correct order. Remove the camshaft drive the intake valves Remove the valve tappets and hydraulic tappets from the cylinder head.
