Setting Attach the flywheel to the crankshaft with new bolts. Fig. 2.163. Lock the flywheel during installation: 1 - a special device
Lock the flywheel using the KM 652 when tightening the screws (Fig. 2.163). Tighten the 6 bolts moment 35 Nm, Dauvergne at +30 ° and + 15 °. Apply (red) for the fixing of the threads. Use new bolts Replace clutch Set the gearbox.
Replacing the rear flange of the crankshaft Withdrawal Remove the flywheel. Fig. 2.164. Removing the plastic ring: 1 - plastic ring, 2 - Screwdriver
Remove the plastic ring with a screwdriver (Fig. 2.164). NOTE Make holes in the areas shown in Figure 2,165 in provisions: 5 h and 7 h, it is the only area where there are behind the O-ring cavity.
221
