Fig. 2.91. Laying new sealant
After the operation put the new sealant (Fig. 2.91). Try to use proprietary sealant or equivalent. After laying a new sealant wait 5 minutes and then mate. Remove excess sealant piece of matter. Tighten mounting bolts.
Removing and installing the power unit (engine 1.4 l) Withdrawal Open the hood. Remove the intermediate axis of the steering column. To do this, the steering wheel in position rectilinear motion. Remove the ignition key and lock the steering column. Fig. 2.92. Bolt fixing the steering column: 1 - Bolt
Loosen the mounting bolt (Figure 2.92). Removing the air filter housing Open the hood. Fig. 2.93. Components, shooting in the dismantling of the air filter: 1 screw fixing the lower rubber support, 2 - wiring harness mass air flow sensor, and 3 - line of ventilation of the fuel tank, 4 - hose, ventilation motor, 5 - air intake hose, 6 - inlet pipe
Remove the air filter housing (Fig. 2.93).
185
