Turn Poly-V belt tensioner in the direction of the arrows in Figure 2.79. Clear Poly-V belt. Remove the lower engine splash guard. Block and squeeze the Poly-V belt tensioner in the direction of the arrow (clockwise). Fig. 2.80. Screw tensioner Poly-V belt: 1 - screws
Loosen the clamping screws and remove the bearing compressor tensioner Poly-V belt (Figure 2.80). Remove the snubber holding his attachment bolt drive gears. Loosen the mounting bolts and remove the bottom of the cover toothed belt with the back cover toothed belt. Setting Attach the bottom part of the new toothed belt cover to the back cover of the toothed belt, tighten the time 6 Nm Attach the snubber to the drive gears toothed belt, tighten the moment 20 Nm Connect Poly-V belt tensioner to the support of the compressor, tighten the moment 25 Nm Squeeze the Poly-V belt tensioner (clockwise) and remove the retainer. Install the lower engine splash guard Replace Poly-V belt. NOTE Make sure that the direction of rotation and position of Poly-V belt compliance. Tighten Poly-V belt, using a Poly-V belt tensioner. Attach the top of the cover toothed belt to the back cover of the toothed belt, tighten the time 6 Nm Replace the air filter housing with the sensor mass air flow. Connect the wiring harness connector sensor mass air flow.
Replacing the toothed belt (engine 2.0 liters) Withdrawal Unplug the wiring harness connector sensor mass air flow. Disconnect the air intake hose, inlet pipe. Remove the air filter housing with the sensor mass air flow. Loosen the mounting bolts and remove the top element covers a toothed belt from the back cover toothed belt. Check direction of rotation of Poly-V belt. Turn Poly-V belt tensioner clockwise. Clear Poly-V belt. Remove the lower engine splash guard. Block and squeeze the Poly-V belt tensioner in the direction of the arrow (clockwise). Loosen the clamping screws and remove the bearing compressor tensioner Poly-V belt. Remove the snubber holding his attachment bolt drive gears. Loosen the mounting bolts and remove the bottom of the cover toothed belt with the back cover toothed belt. Attach a special device KM-6173 to the body of the front axle.
