Fig. 2.73. Re-adjust the tension on the toothed belt tension pulley index: 1 - pointer tension pulley, 2 Tag
Option II: Index tension pulley toothed belt combined to tag «USED» (Figure 2.73). Tighten the attachment bolt tension pulley toothed belt moment 20 Nm Remove the device KM 853 Check after adjustment Rotate the crankshaft by two turns (720 °) in the direction of rotation of the engine in TDC position of the first cylinder and check the adjustment of tension pulley toothed belt. If the pointer tension pulley toothed belt is not combined with the label, repeat the process of adjustment.
Checking the tension of the toothed belt (engine 2.0 l) NOTE This operation applies only to the toothed belt after running. When installing a new toothed belt must be adjusted. The test is performed on the engine is cold - at room temperature. Removing components Disconnect the mass wire from the battery Remove the air filter housing with the sensor mass air flow. Simply unplug the wiring harness connector sensor mass air flow. Relaxed the collar and unscrewing bolts, disconnect the air intake hose inlet pipe. Loosen the mounting bolts and remove the upper lid toothed belt with a toothed belt rear cover Check direction of rotation of Poly-V belt.
174
