Installation components Raise the car. Install the engine splash guard. Lower the car. Insert the oil dipstick hole. Replace the cover expansion tank coolant. Replace spark plugs with sptsialogo tool KM 6363 and then tighten the moment 25 Nm Fig. 2.51. Ignition Module
Replace ignition module, replacing the 4 pads (Figure 2.51). Tighten the two screws fastening point 8 Nm Install the ignition module cover. Replace the front cover of a toothed belt. NOTICE Check that the lids. Tighten the two screws fastening the cover time 6 Nm Replace the air filter housing, tighten the attachment bolt and attach the clamp moment 3,5 Nm Install inlet pipe. Connect the wiring harness air flow sensor. Connect the battery pack. Tighten the nut mounting terminals. Program transient memory. Close the hood.
Checking the pressure loss in the engine (2,0 l) Removing the air filter housing Open the hood. NOTE Before the verification procedure warming up the engine to operating temperature (oil temperature - 80 ° C). Remove the air filter housing with the sensor mass air flow. Unplug the wiring harness connector sensor mass air flow. Fig. 2.52. Components, shooting in the dismantling of the air filter: 1 attachment bolt, 2 - clamp, 3 - the wiring harness connector sensor mass air flow
160
