Fig. 2.34. Mounting electronic module: 1 - an electronic control module engine Simtec 75.1; 2 - inlet manifold
Features Engine management system has the following differences from the engine systems Z 18 XE and Z 16 XEP: - Installed PCB - printed circuit board; - Set the second sensor camshaft; - Set the second temperature sensor.
2.2. Petrol engines - general inspection procedures 2.2.1. General The Test values for all engines, see Table. 2.2, Table. 2.3, Table. 2.3, Table. 2.4, Table. 2.5
Checking the pressure loss in the engine (1,4-1,6 l) Removing the air filter housing Open the hood NOTE Before the verification procedure warming up the engine to operating temperature (oil temperature - 80 ° C).
Fig. 2.35. Components, shooting in the dismantling of the air filter: 1 screw fixing the lower rubber support, 2 - wiring harness mass air flow sensor, and 3 - line of ventilation of the fuel tank, 4 - hose, ventilation motor, 5 - air intake hose, 6 - inlet pipe
Remove the air filter housing (Fig. 2.35). Disconnect the wiring harness sensor mass air flow. Disconnect the fuel tank ventilation line. Disconnect the ventilation hose from the engine air intake hose. Removing the clamp, disconnect the hose from the air intake throttle pipe. Removing the clamp, remove the air filter housing. Loosen the screw fixing the lower rubber support and unplug it. Disconnect the inlet pipe.
