Fig. 1.260. Lifting the vehicle
Insert the handle into the eyelet threaded rod and the rotation of the handle lift the car (Fig. 1.260). NOTE If in the process of lifting toe was not strictly a point of installation, immediately gently lower the car and repeat the procedure to install the jack. Remove the screws and put them wheels so that the thread is not contaminated. Replace the wheel. Fig. 1.261. Tightening wheel bolts
Screw the wheel bolts and lightly tighten them, and the insert face wrench until it stops (Fig. 1.261). Lower the car. Tighten the wheel bolts crosswise, with the insert face wrench until it stops. Before installing the wheel cover to clear the wheel at the site of clamping holders. The symbol of the valve with the back of the wheel cover is for the valve wheel. Install and tighten the cap and wheels, respectively, caps wheel bolts. Replaced wheel, instrument and warning triangle place in the trunk. Check the tire pressure set the wheels when necessary, correct it. Using a torque wrench, check the time of bolting the wheels on the fixed wheel, when necessary, correct it. Replace the defective tire. At the first opportunity to completely replace the wrecked wheel to normal. Initialize the control system tire failure or a system to monitor tire pressure.
Towing Fig. 1.262. Removing the aperture for the tow loop
