Controls Table 24: Status, Maintenance and Error Code Screens Screen
Access/Description Low Fuel Screen Automatically displays when the fuel level is low.
Required Maintenance and Error Code Screens Maintenance Required Screen Displays in the screen rotation along with status screens when scheduled maintenance is required. See page “Maintenance Schedule” on page 116. To dismiss this screen, press and hold the interface button (Z, Fig. 8). This screen will display in rotation when scrolling through the status screens. After 1 full rotation of all screens, the display will freeze on this screen. Engine Error Code Screen Displays in the screen rotation along with status screens when engine errors occur. See “Yanmar Engine Diagnostic Trouble Codes (DTC) - Models 1750RT/ 2100RT” on page 322 or “Deutz Engine Error Codes - Model 2500RT” on page 330. Up to 3 errors can be displayed on a single screen; additional screens are displayed if more than 3 errors occur. The error code screen is dismissed when the underlying problem is solved -error code screens take precedence over other screens. Drive / Valve Error Code Screen Displays in the screen rotation along with status screens when drive / valve system errors occurs. Up to nine drive / valve error codes can be displayed. See “Drive and Valve Error Codes” on page 335. Limp Mode Activated Screen Limp mode allows limited drive function when drive system errors (3-10) occur which disable able the drive system for safety reasons. Two limp mode codes can be displayed –”38” and “39”. See “Travel Drive Error Condition Operation (Limp Mode)” on page 94. Module Communication Error Code Screen Displays in the screen rotation along with status screens when module communication errors occurs. Up to nine module communication error codes can be displayed. DPF Stationary Regeneration Request Screen Models 1750RT and 2100RT with Tier 4 Engines Displays when stationary Diesel Particulate Filter (DPF) regeneration is required. See “Diesel Particulate Filter (DPF) Regeneration Procedures” on page 81. DPF Filter Ash Cleaning Required Models 1750RT and 2100RT with Tier 4 Engines Displays when Diesel Particulate Filter (DPF) core exchange is required. See “Diesel Particulate Filter (DPF) Regeneration Procedures” on page 81 Printed in U.S.A.
53
50940165/C0718
