Electronics Diagnostic Kit D E
B
A
C
F
Displayed Telemetry Information The table below describes the information displayed by the software. The telemetry information is pulled from the drive / valve controller on the compact track loader. Values are updated as they change. Item
Description
A
Telemetry item description
B
Real-time telemetry values
C
Specified parameter ranges
D
Machine controller and software part number identification
E
Error code identification / descriptions
F
Software display version number
50940165/C0718
Details Identifies the specific telemetry item associated with values displayed in area (B). Real-time values from drive / valve controller on the compact track loader are displayed. Green indicates static values; blue indicates changing values. Identifies acceptable ranges for values displayed in area (B). Values displayed in area (B) outside acceptable ranges indicate error conditions. Displays the drive/valve controller hardware and software part numbers and revision levels. Lists information about possible error codes that could be displayed in area (B). Refer to “Troubleshooting”, starting on page 313, for additional information. Identifies the diagnostic kit software display version.
312
