Electrical/Control Systems Tail Light Bulb Replacement
Front Work Light Bulb
WARNING U
T
BEFORE beginning this service procedure, shut down the machine according to “Mandatory Safety Shutdown Procedure” on page 22.
1. Twist tail light bulb socket (W, Fig. 554) counter-clockwise and remove it from the tail light housing.
Rear Work Light Bulb
U T W
Fig. 554 – Tail Light
2. Pull bulb (F, Fig. 555) out of socket (L). Discard the spent bulb. Fig. 553 – Work Light Bulbs F
IMPORTANT: Do not touch new halogen bulbs with bare fingers. Oils from skin can etch the bulb glass and cause the bulb to fail prematurely. Wear clean gloves or use a clean rag to handle new bulbs.
L
3. Plug connector (T) onto new bulb (U). • Front work light replacement bulb is GE 885 or equivalent. • Rear work light replacement bulb is GE 862 or equivalent [Manitou part # 122488]. 4. Install the new bulb into the work light and twist to lock it in place.
50940165/C0718
Fig. 555 – Tail Light Bulb
3. Push replacement bulb (F) into socket (L) until it snaps into place. Replacement bulb is GE3157 or equivalent [Manitou part # 50221053].
