Hydraulic Equipment NOTE: The gear pump for machines with the high-flow auxiliary option is shown in Fig. 498. Gear pump for standard flow auxiliary hydraulics is shown in Fig. 499.
Later Machines R
S
Early Machines R S
Fig. 499 – Standard Flow Auxiliary Hydraulics Gear Pump
IMPORTANT: Use a new O-ring [Manitou part # 132248] and new mounting screws [Manitou part # 50280004] when re-installing the gear pump.
S Fig. 500 – Remove Hydrostatic Pump Mounting Screws
WARNING Do NOT use any lifting attachments (slings, chains) that are damaged or of inadequate rated capacity.
12. Support hydrostatic pump (R, Fig. 500) with an appropriate lifting device. NOTE: The hydrostatic pump weighs approximately 90-113 kg (200-250 lbs.). 13. Remove fasteners (S) securing the hydrostatic pump to the engine flywheel housing.
