1750RT/2100RT interim Tier 4 Engine Removal/Installation 23. Remove cap and plug, and connect hose (Y, Fig. 455) to fitting (B) on the radiator. Tighten securely.
25. Connect lower coolant hose (A, Fig. 457) to the coolant pump using hose clamp (B). Tighten securely.
D B
E
C F Y
B A Fig. 457 – Radiator Hoses Fig. 455 – Upper Hydraulic Hose
24. Remove cap and plug, and connect hose (Z, Fig. 456) to the oil filter. Tighten securely.
26. Connect upper coolant hose (C) to the thermostat housing using hose clamp (D) Tighten securely. 27. Connect overflow hose (E) using hose clamp (F). Tighten securely.
Z
Fig. 456 – Hydraulic Hose to Filter
50940165/C0718
252
Printed in U.S.A.
