1750RT/2100RT interim Tier 4 Engine Removal/Installation 14. Place clamp (H, Fig. 450) loosely over engine exhaust tube and install muffler (D) using 4 carriage bolts (E), flat washers (F), and locknuts (G). Tighten securely.
16. Loosely install 3 carriage bolts (I, Fig. 451), flat washers (J), and nuts (K) on the engine oil filter assembly (L).
IMPORTANT: Make sure muffler exit tube fits over the engine exhaust tube when installing.
D
E
F
M
G
I
J
K
L E
F
G
D M
H
Fig. 450 – Muffler
L
15. Secure muffler (D) to engine exhaust tube using clamp (H). Tighten securely.
Fig. 451 – Engine Oil Filter
17. To install the engine oil filter assembly (L) to the frame bracket (M), insert the heads of the carriage bolt through the large openings in the bracket (M) and slide the filter assembly all the to the back of the slots in bracket (M). Tighten nuts (K) to secure the assembly to the frame bracket.
