Mustang Compact Loader 1750RT 2100RT 2500RT Service Manual (50940165)

1750RT/2100RT interim Tier 4 Engine Removal/Installation 75. Remove nut (E, Fig. 438) and screw (F) from left rear motor mount (G), and remove hose bracket (H).

I

K J F

E

G

Fig. 439 – Remove Engine

H

Fig. 438 – Motor Mount Hardware

76. Remove screws (I) and washers (J) from both rear motor mounts. Discard screws (I), but retain washers for installation.

NOTE: Screws (I) should be replaced for installation. Refer to the parts manual for ordering information.

NOTE: Use caution when removing engine, as some hoses may need to be moved aside.

77. Remove engine (K, Fig. 439) using an engine hoist or other appropriate lifting device.

50940165/C0718

246

Printed in U.S.A.
