1750RT/2100RT interim Tier 4 Engine Removal/Installation NOTE: Threading for mounting bracket holes for lift bracket (X) is M12-1.75. G H G
H
X Y
Fig. 409 – Front Motor Mount Screws Fig. 407 – Hydraulic Pump
27. Remove cable ties (W).
24. Lift the hydraulic pump slightly, and pull the pump forward until it clears the engine.
28. If the engine is equipped with a turbo: a. Remove cable tie (A, Fig. 410).
NOTE: A come-along hand winch may be required to pull the hydraulic pump forward.
25. Remove screws (E, Fig. 408) and hose/cable clamps (F) from the engine block.
U
V A E
B C
D
Z
Fig. 410 – Turbocharger Intake Tube F
b. Remove cable tie (A).
Fig. 408 – Hose/Cable Clamps
c. Pull heater supply (V) and return (U) hoses out of the engine compartment.
26. Remove screws (G, Fig. 409) and large flat washers (H) from both front motor mounts. Discard screws (G), but retain washers for installation.
d. Disconnect wiring connector (B) from sensor (C). e. Loosen clamp (D), and remove intake tube (Z). Cover the intake opening on the turbocharger to prevent debris from entering the turbocharger.
NOTE: Screws (G) should be replaced for installation. Refer to the parts manual for ordering information. Printed in U.S.A.
237
50940165/C0718
