Models 1750RT/2100RT Tier 4 Engine Removal/Installation 61. On machines equipped with air conditioning: a. Connect supply (Q, Fig. 395) and return (R) air conditioning lines to the air conditioning condenser.
Q
R
62. Fill the hydraulic system reservoir according to “Changing Hydraulic Oil and Filter” on page 132. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper hydraulic oil specifications. 63. Fill the cooling system according to “Draining/ Refilling Cooling System” on page 125. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper coolant specifications. 64. Fill the fuel tank according to “Adding Fuel” on page 128. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper fuel specifications. 65. Fill the windshield according to “Windshield Washer Reservoir” on page 154. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper fuel specifications.
Fig. 395 – Connect Air Conditioning Lines (Air Conditioned Machines Only)
66. Reconnect the negative cable to the battery.
b. Connect the condenser cooling fan connector (S, Fig. 396) to the main harness connector. c. Recharge the air conditioning system with refrigerant. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper refrigerant specifications.
S
Fig. 396 – Connect Condenser Cooling Fan Connector (Air Conditioned Machines Only)
