Models 1750RT/2100RT Tier 4 Engine Removal/Installation 56. Route engine compartment access door harness (E, Fig. 392) into the engine compartment.
58. Connect the engine compartment access door harness (F) to the main harness (H). 59. Lift engine compartment cover (I, Fig. 394) into position using an appropriate lifting device.
M
I
E
J
Fig. 392 – Install Engine Access Door
K
57. Connect engine compartment access door harness connector (F, Fig. 393) to main harness. Secure the door and engine harnesses to the radiator shroud using harness retainers (X).
L
Fig. 394 – Install Engine Compartment Cover
60. On both sides of engine compartment cover (I): a. Install pin (J) and spring clip (K). b. Connect support strut to bracket (L) and secure using nut (M). Tighten securely.
F
X
Fig. 393 – Compartment Door Harness/Engine Harness Ties
