Mustang Compact Loader 1750RT 2100RT 2500RT Service Manual (50940165)

Models 1750RT/2100RT Tier 4 Engine Removal/Installation 52. Place fiber washer (U, Fig. 388) on the top of upper engine compartment door hinge (V).

Y

Z

U

Z A

V

Fig. 388 – Install Fiber Washer

53. Carefully lift engine compartment access door (W, Fig. 389) into position using an appropriate lifting device. Align pins (X) with the holes in mounting bracket (Y) and lower the door until the pins seat in the holes.

Fig. 390 – Install Engine Access Door Lower Mounting Hardware

55. Install screw (B, Fig. 391), 2 flat washers (C), and nut (D) through the hole in the pin. Tighten securely.

C

W

B

Y

C D X Fig. 391 – Install Engine Access Door Upper Mounting Hardware Fig. 389 – Install Engine Access Door

54. Install screw (Y, Fig. 390), 2 flat washers (Z), and nut (A) through the hole in the pin. Tighten securely.

50940164/C0718

230

Printed in U.S.A.
