Models 1750RT/2100RT Tier 4 Engine Removal/Installation 25. Plug DPF electrical connections (A through C, Fig. 371). The connections are labeled as follows:
27. Connect oil pressure ring connector (H, Fig. 372) to oil sender (I) at the left front of the engine under the four engine electrical connectors. Tighten securely.
A. “C180 DPF PRESSURE SENSOR” B. “C203 DPF MID-TEMP SENSOR” C. “C202 DPF INLET TEMP SENSOR”
A H I B
C Fig. 372 – Oil Pressure Switch Connection Fig. 371 – DPF Electrical Connections
28. Connect “C182” engine connector (F, Fig. 373) and “C181” starter solenoid connector (G).
26. Raise the ROPS/FOPS according to “Raising ROPS/FOPS” on page 140.
WARNING Always secure the ROPS/FOPS in the tilted position with pins and spring pins. Never allow anyone under the ROPS/FOPS if the tilt securing pins are not in place.
F G
Fig. 373 – Engine/Starter Electrical Connections
Printed in U.S.A.
225
50940164/C0718
