Models 1750RT/2100RT Tier 4 Engine Removal/Installation 7. Carefully lift radiator/hydraulic oil cooler assembly (N, Fig. 358) into place using an appropriate lifting device.
4. Connect and secure wire (R, Fig. 356) to terminal on alternator (N) using nut (O).
NOTE: Radiator (N) is heavy. A hoist or other similar lifting device is recommended for lifting the radiator into place.
N
O P N R
T
Fig. 356 – Alternator Electrical Connections
P
5. Connect and secure wire (T) to terminal on alternator (N) using nut (P). 6. Connect and secure wires (A, Fig. 357) and (D) to terminal on starter motor (S) using nut (Z).
Q Fig. 358 – Lower Radiator Hydraulic Hose
8. Remove cap and plug and connect lower hydraulic hose (P) to fitting (Q).Tighten securely.
D
Z A
S Fig. 357 – Starter Motor Electrical Connections
