Models 1750RT/2100RT Tier 4 Engine Removal/Installation 65. Remove nut (O) and disconnect wire (R) from alternator (N).

NOTE: Use caution when removing engine to prevent damaging hoses, components and wire harnesses.

66. Remove nut (E, Fig. 352) and screw (F) from left rear motor mount (G), and remove hose bracket (H) securing fuel line (X). Retain all hardware for installation.

I

68. Carefully remove engine (K, Fig. 353) using an engine hoist or other appropriate lifting device.

J F

E

K

X G

H

Fig. 352 – Motor Mount Hardware

67. Remove screws (I) and washers (J) from both rear motor mounts. Discard screws (I), but retain washers for installation.

Fig. 353 – Lifting Engine

NOTE: Screws (I) should be replaced for installation. Refer to the parts manual for ordering information.
