Models 1750RT/2100RT Tier 4 Engine Removal/Installation 38. Remove locknut (J, Fig. 332), screw (K), and 2 washers (L) from the upper door mount.
35. Disconnect engine compartment access door harness connector (F, Fig. 330) from main harness. Remove harness retainers (X) securing the door and engine harnesses to the radiator shroud.
J
L
L K F Fig. 332 – Engine Access Door Upper Mounting Hardware
X
39. Remove locknut (M, Fig. 333), screw (N), and 2 washers (O) from the lower door mount.
Fig. 330 – Compartment Door Harness/Engine Harness Ties
36. Support engine compartment access door (I, Fig. 331) using an appropriate lifting device.
N
O
Z
O M
H
I Fig. 333 – Engine Access Door Lower Mounting Hardware I
40. Lift latch pin (Z) and close, but do not latch, the engine compartment access door (I).
Fig. 331 – Engine Access Door
37. Remove engine compartment access door harness (H) from the engine compartment, and secure the harness to the door.
