Model 2500RT Engine Removal/Installation 46. Connect the engine compartment access door harness (K, Fig. 308) to the left side engine compartment main harness.
50. On machines equipped with air conditioning: a. Connect supply (Q, Fig. 310) and return (R) air conditioning lines to the air conditioning condenser.
Q K
R
Fig. 308 – Connect Engine Compartment Access Door Harness
Fig. 310 – Connect Air Conditioning Lines (Air Conditioned Machines Only)
47. Lift engine compartment cover (A, Fig. 309) into place using an appropriate lifting device.
b. Connect the condenser cooling fan connector (S, Fig. 311) to the main harness connector. c. Recharge the air conditioning system with refrigerant. Refer to “Fluids/Lubricants Types and Capacities” on page 37 for proper refrigerant specifications.
A B C E D
S
Fig. 309 – Install Engine Compartment Cover
48. Install a pin (E) and spring clip (D). 49. Connect support strut (C) to the bracket and secure using nut (B).
50940165/C0718
Fig. 311 – Connect Condenser Cooling Fan Connector (Air Conditioned Machines Only)
