Model 2500RT Engine Removal/Installation 63. Remove nut (U, Fig. 266) and screw (V) from the left front motor mount, and remove the hose retainer.
65. Remove the screw (Y, Fig. 268) and washer (Z) from the right front motor mount. Discard screw (Y), but retain washer (Z) for installation. NOTE: Screw (Y) should be replaced for installation. Refer to the parts manual for ordering information.
V Y U
Z
Fig. 266 – Remove Hose Retainer Hardware
64. Remove screw (W, Fig. 267) and washer (X) from the left front motor mount. Discard screw (W), but retain washer (X) for installation.
Fig. 268 – Remove Right Motor Mount Hardware
NOTE: Use caution when removing the engine, as some hoses may need to be moved aside.
NOTE: Screw (W) should be replaced for installation. Refer to the parts manual for ordering information.
66. Remove the engine (A, Fig. 269) using an appropriate lifting device.
A
W X
Fig. 269 – Remove Engine Fig. 267 – Remove Left Motor Mount Hardware
