Model 2500RT Engine Removal/Installation 37. Loosen clamp (U, Fig. 247) securing the air cleaner to the intake tube (V).
41. Disconnect hose retainer (X, Fig. 249), and pull heater supply and return hoses (Y) from the engine compartment.
U
V
Y
X
Fig. 247 – Loosen Air Cleaner Clamp
38. Disconnect wiring connector (W, Fig. 248) from the air cleaner pressure sensor.
Fig. 249 – Disconnect Hose Retainer
42. Loosen the clamp (Z, Fig. 250) securing the air intake tube to the turbocharger (A).
A
W Z
Fig. 248 – Disconnect Air Cleaner Sensor Connector Fig. 250 – Loosen Turbocharger Clamp
39. Raise the ROPS/FOPS according to “Raising ROPS/FOPS” on page 140.
WARNING Secure the ROPS/FOPS in the tilted position. Do not allow anyone under the ROPS/FOPS if the tilt securing mechanism is not in place.
40. Remove hydraulic pump assembly. See “Hydrostatic Pump Removal” on page 270. 50940165/C0718
