Model 2500RT Engine Removal/Installation 16. Lift the engine compartment access door just high enough for pins (P, Fig. 229) to clear the brackets (Q), and remove the door.
13. Remove locknut (J, Fig. 227), screw (K), and 2 washers (L) from the upper door mount.
CAUTION
J
L
The door is heavy. A hoist or other similar lifting device is recommended when removing the door.
IMPORTANT: There is a fiber washer (R, Fig. 230) located between the door and frame brackets.
L K
Fig. 227 – Remove Engine Access Door Upper Mounting Hardware Q
14. Remove locknut (M, Fig. 228), screw (N), and 2 washers (O) from the lower door mount.
N
P
O
Fig. 229 – Remove Engine Access Door Z
O
17. Remove fiber washer (R, Fig. 230) from the upper and lower door mounting brackets (Q).
M
I Fig. 228 – Remove Engine Access Door Lower Mounting Hardware V
15. Lift latch pin (Z) and close, but do not latch, the engine compartment access door (I).
V
U
Fig. 230 – Remove Fiber Washers
Printed in U.S.A.
183
50940165/C0718
